Gridfinity Hex Bins Light (rotated grid) all sizes

Note, I accidentally generated these with the hex grid rotated, meaning the flat top was facing up. This will be harder to print as the grid will require bridging. Some people liked this looks so instead of replacing them all, I have reposed the model and kept this one as is Gridfinity Hex bins Light.

A light version of my Gridfinity Hex Cups, with a hex pattern cut out of the walls and a smooth efficient base. all sizes - 999 models.


The smooth efficient base reduces filament usage.

For example;

• w2_d3_h6:
  • uses 55g print time 3h3min
• w2_d3_h6 smooth efficient floor:
  • uses 35g print time 2h21min

Note, print times are relative these we calculated for a mks3 on draft.

Options Widths = [0.5, 1, 2, 3, 4, 5, 6] Depths = [1, 2, 3, 4, 5, 6] Heights = [2, 2.5, 3-37] I really like this model, I find the pattern very satisfying.  Generated using the Gridfinity Extended OpenSCAD

Design by ostat on MakerWorld (license: BY).
